10.1-inch Industrial Embedded Monitor
10.1-inch industrial display monitor,featuring a metal casing that effectively addresses signal interference,offers clear and high-quality image quality and advanced functions,and is capable of reliable 24/7 operation for years in harsh factory environments.
Industrial Monitor with Metal Enclosure
Product Details
Related Cases
Related Post
Screen Parameters
Panel Type Industrial：10.1″ Control A style TFT
Resolution：1280*800
Pixel per inch (PPI)：86PPI
Aspect ratio：16:10
Gray-scale response time：5ms
Display colors：16.7M
Brightness：300 cd/m²(customizable higher brightness)
Viewing angle：85/85/85/85(L/R/U/D); (Customizable 178° full view angle)
Touch-type:Resistive / capacitive / non-touch screen
Number of touches:≥ 50 million times
Operating temperature:-10°C ~ +70°C
Storage temperature:-30°C ~ +80°C
O/I interface parameters
Signal Interface:DVI, HDMI, VGA
Power connector:DC with ring attachment (optional DC terminal block)
Touch interface:USB
Other interfaces:Audio input and output
