19 inch LVDS 1280×1024 High Brightness LCD with 1000 Nits
19" sunlight readable, high brightness (1000 nits)
Resolution：1280*1024
Touch method：on-Cell Touch, I²C
Aspect ratio：4：3
Viewing angle：85/85/80/80
Backlight power consumption：25W
Operating temperature：-20°C ~ +70°C
Resolution：1280*1024
Touch method：on-Cell Touch, I²C
Aspect ratio：4：3
Viewing angle：85/85/80/80
Backlight power consumption：25W
Operating temperature：-20°C ~ +70°C
High Brightness LCD for Sunlight Viewing
Product Details
Related Cases
Related Post
Description：19″ TFT LCD, 1000 nits LED backlight,
size：19 inch
Display area (mm)：376.32(W)×301.056(H) mm
Module size: 396(W) x324(H) x11.7(D)mm
Brightness：1000 cd/m²
Resolution：1280*1024
Aspect ratio：4:3
Pixel per inch (PPI)：86PPI
Viewing angle：85/85/80/80
Display colors：16.7M
Signal Type：30 pins LVDS (2 ch, 8-bit)
Backlight power consumption:67V/360 MA
Operating temperature:-20°C ~ +70°C
Storage temperature:-30°C ~ +80°C
