10.1″ 1280*800 1500nits LCD

SIZE Size: 10.1 inch
External dimensions: 228.5*149*4.5mm
Display parameters display area: 217(H)x135.6(V)mm
Color: 16.7M
resolution ratio: 1280×800
Brightness: 500/1000/1500 nits
Interface type: LVDS 40Pin
Backlight type: LED
viewing angle:  178°/178°
Power consumption: 12W
working temperature:  -20 -70℃
Storage temperature:  -30 -80℃
Display motherboard port HDMI: HDMI *1
Speaker: 5W*2 speaker
power input 12V/2A
Key board Five keys PCB
Audio input: 3.5mm audio port*1


10.1″ industrial grade sunlight readable LCD, with high brightness500-1000-1500 nits, it produce sharp images, crisp text and lifelike colors. The Durapixel LED backlight technology ensures high reliability and low power consumption, suitable for outdoor application, kiosk, factory automation, medical,military, transportation and gaming application.
