14 Inch Tempered Glass Touchscreen 16:9
MODEL: HT-51586
BRIGHTNESS
0
nits
SIZE
inch
RESOLUTION
ASPECT RATIO
Technical Highlights
certification standard
Need customized solution?
Our engineering team is always ready to provide you with professional technical support and flexible customized services.
Understand light customization servicesTechnical Specifications
| No. | Item | Specification |
|---|---|---|
| 1 | Operating Conditions | DC 2.8~3.6V |
| 2 | Supported Operation | Multi-touch |
| 3 | Accuracy | ±1mm @ 10mm |
| 4 | Surface Hardness | >6H |
| 5 | Operating Temperature | -20℃~+70℃ |
| 6 | Storage Temperature | -40℃~+85℃ |
| 7 | Light Transmittance | >84% |
| 8 | Structure Type | G/G (Glass-to-Glass) |
| 9 | Service Life | 35,000,000 touches |
| 10 | Environmental Compliance | RoHS Compliant |
| 11 | ESD Protection | Air ±4KV |
| 12 | Unspecified Tolerance | 0.2mm |
